# 31-5093
Combination ratchet spanners
Items:
1812
Article №: V6752-15
VIGOR Ratchet Ring Open-ended Spanner V6752-15 Length: 228mm
- Number of teeth (ratchet mechanism): 72
- Length [mm]: 228
- Tightening angle [degrees]: 5
- Spanner Size 1 [mm]: 15
- Mouth Thickness [mm]: 7,5
- Ring Thickness [mm]: 8,4
- Output end (profile): Male Hex
- Condition: New
Article №: 7 UR 18
GEDORE Ratchet Ring Open-ended Spanner 7 UR 18 Spanner Size: 18,0
- Material: Chrome Vanadium Steel
- Surface: Chromed
- Spanner Size: 18,0
- Ring Position [degrees of angle]: 13
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 182
- Number of Parts [parts]: 1
- Total Length [mm]: 240
- Total width [mm]: 40
- Total height [mm]: 21
- Net weight [kg]: 0,178
- Head Width [mm]: 34,6
- Head Height [mm]: 11
- Swivel Range [degrees]: 6
- Head Width 2 [mm]: 40
- Head Height 2 [mm]: 6,1
- Condition: New
More
Article №: R07300130
GEDORE Ratchet Ring Open-ended Spanner R07300130 Spanner Size: 13
- Material: Chrome Vanadium Steel
- Surface: Satined Matt, Chromed
- Spanner Size: 13
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 120
- Number of Parts [parts]: 1
- Total Length [mm]: 180
- Net weight [kg]: 0,12
- Head Width [mm]: 26,8
- Spanner Size 1 [mm]: 13
- Head Height [mm]: 7
- Similar DIN standards (Screwing Tools): DIN 3113 (ring spanner)
- Swivel Range [degrees]: 5
- Head Width 2 [mm]: 26
- Head Height 2 [mm]: 9,3
- Condition: New
More
Article №: V4951-21
VIGOR Ratchet Ring Open-ended Spanner V4951-21 Spanner Size: 21, 21 mm, Length: 254mm, Weight: 214g
- Surface: Chromed, Polished
- Length [mm]: 254
- Work side (profile): Male Hex, Double Hexagon
- Spanner Size: 21, 21 mm
- Weight [g]: 214
- Condition: New
Article №: R07200160
GEDORE Ratchet Ring Open-ended Spanner R07200160
- Material: Chrome Vanadium Steel
- Number of teeth (ratchet mechanism): 72
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 165
- Number of Parts [parts]: 1
- Total Length [mm]: 215
- Total width [mm]: 35
- Total height [mm]: 20
- Net weight [kg]: 0,171
- Head Width [mm]: 35,7
- Spanner Size 1 [mm]: 16
- Head Height [mm]: 7,9
- Similar DIN standards (Screwing Tools): DIN 3113 (ring spanner)
- Swivel Range [degrees]: 5
- Head Width 2 [mm]: 31,8
- Head Height 2 [mm]: 9,9
- Condition: New
More
Article №: R07200170
GEDORE Ratchet Ring Open-ended Spanner R07200170
- Material: Chrome Vanadium Steel
- Number of teeth (ratchet mechanism): 72
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 199
- Number of Parts [parts]: 1
- Total Length [mm]: 230
- Total width [mm]: 38
- Total height [mm]: 20
- Net weight [kg]: 0,197
- Head Width [mm]: 38,3
- Spanner Size 1 [mm]: 17
- Head Height [mm]: 8
- Similar DIN standards (Screwing Tools): DIN 3113 (ring spanner)
- Swivel Range [degrees]: 5
- Head Width 2 [mm]: 34,1
- Head Height 2 [mm]: 10,6
- Condition: New
More
Article №: 7 UR 19
GEDORE Ratchet Ring Open-ended Spanner 7 UR 19 Spanner Size: 19,0
- Material: Chrome Vanadium Steel
- Surface: Chromed
- Spanner Size: 19,0
- Ring Position [degrees of angle]: 13
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 218
- Number of Parts [parts]: 1
- Total Length [mm]: 252
- Total width [mm]: 44
- Total height [mm]: 22
- Net weight [kg]: 0,218
- Head Width [mm]: 36,3
- Head Height [mm]: 11,7
- Swivel Range [degrees]: 6
- Head Width 2 [mm]: 42
- Head Height 2 [mm]: 6,4
- Condition: New
More
Article №: 6754
LASER TOOLS Ratchet Ring Open-ended Spanner 6754 Spanner Size: 14 x 15mm, Length: 360mm
- Spanner Size: 14 x 15mm
- Drive side (profile): Hexagon
- Material: Chrome Vanadium Steel
- Length [mm]: 360
- Condition: New
Article №: V6752-16
VIGOR Ratchet Ring Open-ended Spanner V6752-16 Length: 245mm
- Number of teeth (ratchet mechanism): 72
- Length [mm]: 245
- Tightening angle [degrees]: 5
- Spanner Size 1 [mm]: 16
- Mouth Thickness [mm]: 7,7
- Ring Thickness [mm]: 10
- Output end (profile): Male Hex
- Condition: New
Article №: 503.4819-E
KS TOOLS Ratchet Ring Open-ended Spanner 503.4819-E Spanner Size: 19, Weight: 220g
- Surface: Satined Matt, Chromed
- Material: Chrome Vanadium Steel
- Weight [g]: 220
- Fork Position [degrees of angle]: 15
- Outer Diameter 2 [mm]: 39,2
- Torque from [Nm]: 387
- Torque to [Nm]: 387
- Height 2 [mm]: 8,6
- Height 1 [mm]: 11,2
- Number of teeth (ratchet mechanism): 72
- Ring Position [degrees of angle]: 180
- Spanner: Movable (joint)
- Thread Type: with metric thread
- Connector type: Flank Traction
- DIN/ISO: DIN 3113, ISO 3318
- Spanner Size: 19
- Total Length [mm]: 215
- Diameter [mm]: 33,9
- Condition: New
More
Article №: FHRCW16
SEALEY Ratchet Ring Open-ended Spanner FHRCW16 Spanner Size: 16
- Spanner Size: 16
- Spanner: Movable (joint)
- Number of teeth (ratchet mechanism): 72
- Material: Chrome Vanadium Steel
- Condition: New
Article №: R07300170
GEDORE Ratchet Ring Open-ended Spanner R07300170 Spanner Size: 17
- Material: Chrome Vanadium Steel
- Surface: Satined Matt, Chromed
- Spanner Size: 17
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 330
- Number of Parts [parts]: 1
- Total Length [mm]: 233
- Net weight [kg]: 0,33
- Head Width [mm]: 37
- Spanner Size 1 [mm]: 17
- Head Height [mm]: 8,3
- Similar DIN standards (Screwing Tools): DIN 3113 (ring spanner)
- Swivel Range [degrees]: 5
- Head Width 2 [mm]: 32,6
- Head Height 2 [mm]: 10,9
- Condition: New
More
Article №: R07100200
GEDORE Ratchet Ring Open-ended Spanner R07100200 Spanner Size: 20
- Material: Chrome Vanadium Steel
- Surface: Satined Matt, Chromed
- Spanner Size: 20
- Number of teeth (ratchet mechanism): 72
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 336
- Number of Parts [parts]: 1
- Total Length [mm]: 285
- Total width [mm]: 45
- Total height [mm]: 13
- Net weight [kg]: 0,41
- Head Width [mm]: 45,8
- Spanner Size 1 [mm]: 20
- Head Height [mm]: 10,2
- Similar DIN standards (Screwing Tools): DIN 3113 (ring spanner)
- Swivel Range [degrees]: 5
- Head Width 2 [mm]: 42
- Head Height 2 [mm]: 13
- Condition: New
More
Article №: RCW19
SEALEY Ratchet Ring Open-ended Spanner RCW19 Spanner Size: 19, Length: 253mm
- Number of teeth (ratchet mechanism): 72
- Spanner Size: 19
- Length [mm]: 253
- Material: Chrome Vanadium Steel
- Condition: New
Article №: FHRCW19
SEALEY Ratchet Ring Open-ended Spanner FHRCW19 Spanner Size: 19, Length: 250mm
- Spanner: Movable (joint)
- Number of teeth (ratchet mechanism): 72
- Length [mm]: 250
- Spanner Size: 19
- Material: Chrome Vanadium Steel
- Condition: New
Article №: R07200180
GEDORE Ratchet Ring Open-ended Spanner R07200180
- Material: Chrome Vanadium Steel
- Number of teeth (ratchet mechanism): 72
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 214
- Number of Parts [parts]: 1
- Total Length [mm]: 239
- Total width [mm]: 40
- Total height [mm]: 21
- Net weight [kg]: 0,219
- Head Width [mm]: 40,1
- Spanner Size 1 [mm]: 18
- Head Height [mm]: 8,5
- Similar DIN standards (Screwing Tools): DIN 3113 (ring spanner)
- Swivel Range [degrees]: 5
- Head Width 2 [mm]: 34
- Head Height 2 [mm]: 11
- Condition: New
More
Article №: V4951-22
VIGOR Ratchet Ring Open-ended Spanner V4951-22 Spanner Size: 22, 22 mm, Length: 263mm, Weight: 250g
- Surface: Chromed, Polished
- Length [mm]: 263
- Work side (profile): Male Hex, Double Hexagon
- Spanner Size: 22, 22 mm
- Weight [g]: 250
- Condition: New
Article №: 7 R 24
GEDORE Ratchet Ring Open-ended Spanner 7 R 24 Spanner Size: 24,0
- Material: Chrome Vanadium Steel
- Surface: Chromed
- Spanner Size: 24,0
- Fork Position [degrees of angle]: 15
- Net Weight [g]: 455
- Number of Parts [parts]: 1
- Total Length [mm]: 325
- Total width [mm]: 54
- Total height [mm]: 15
- Net weight [kg]: 0,52
- Head Width [mm]: 48
- Head Height [mm]: 14,8
- Swivel Range [degrees]: 6
- Head Width 2 [mm]: 52,5
- Head Height 2 [mm]: 7,9
- Condition: New
More
Article №: V6752-17
VIGOR Ratchet Ring Open-ended Spanner V6752-17 Length: 259mm
- Number of teeth (ratchet mechanism): 72
- Length [mm]: 259
- Tightening angle [degrees]: 5
- Spanner Size 1 [mm]: 17
- Mouth Thickness [mm]: 7,9
- Ring Thickness [mm]: 10
- Output end (profile): Male Hex
- Condition: New
Article №: 503.4224-E
KS TOOLS Ratchet Ring Open-ended Spanner 503.4224-E Spanner Size: 24, Weight: 470g
- Surface: Chromed
- Material: Chrome Vanadium Steel
- Weight [g]: 470
- Fork Position [degrees of angle]: 15
- Outer Diameter 2 [mm]: 51,8
- Torque from [Nm]: 610
- Torque to [Nm]: 610
- Height 2 [mm]: 10
- Height 1 [mm]: 14,5
- Number of teeth (ratchet mechanism): 72
- Spanner: Simple
- Thread Type: with metric thread
- Connector type: Flank Traction
- DIN/ISO: DIN 3113, ISO 3318
- Spanner Size: 24
- Total Length [mm]: 322
- Diameter [mm]: 46
- Condition: New
More
Customers also shopped for
Payment methods
Spares parts Shop
-
Best pricesBuycarparts.co.uk guarantees high-quality car parts at very attractive prices.
-
Wide choiceWe currently have over 500,000 car parts in our product range.
-
Save on shippingFree shipping within the UK applies to orders over £ 130 and excludes bulky items, tyres, or core parts.
-
Fast delivery
Shipping methods
-
Similar groups of products:
Combination ratchet spanner is a tool for work with threaded fastening elements, on one side of which the open end head is, and the wrench profile with the ratchet – on the other side. Such devices can be used when working with bolted connections located both on open surfaces and hard-to-reach places. Ratchet significantly simplifies maintenance of fastenings reducing time of their mounting or dismounting.
Types of combination ratchet spanners
Both working profiles of such a tool always have the same size, for example, 8, 10, 12, 13, 14, 17, 19 mm. They are made of durable materials which are able to withstand significant loads. In most cases they are made of tool steel, for instance, chrome-vanadium. Most tools have a protective coating of nickel, chrome or other materials with high anti-corrosion characteristics.
Apart from classic models, manufacturers offer tools with the joint mechanism located in the connection place of the ring-type part. With the help of it one can change its slope towards the handle in 0° – 180° range. It provides access to fastening elements located in hard-to-reach places.
The ratchet mechanism of the ring head can have different quantity of teeth: the more teeth are, the less the tool rotation angle during work is, and the smoother it rotates. Also, there can be rotation direction switch. Price of these products is higher.
Tips on combination ratchet spanners use
- Use the tools in strict accordance with sizes of mounting and demounting fastening elements. If you often repair and service different car units, it is better to buy a tool kit for working with fastenings.
- Don’t overload the accessories. Don’t make too much effort when tightening. Don’t try to unscrew old rusted bolts using the wrench profile.
- Before using, necessarily check tools for defects presence. Don’t use defected tools.
